Rig Inventory
DRAWWORKS
1,500 Hp, Continental Emsco C1 with Baylor 6032 Electric Brake
MOBILITY
Uni-Directional Skid System up to 90’
​
​
MAST
DSI 142 FT - 750,000 LB Static Hook Load
​
SUBSTRUCTURE
DSI 31’ Floor Height Box on Box – 400,000 Setback
GENERATOR
(3) Caterpillar 3512C Diesel Engines w/ 1,365 KW Generators
CONTROL HOUSE
1600A 4x4 Bay M&I Electric with Dynamic Braking and PLC Failover System
MUD PUMPS
(3) 1600 HP 12P160 p/b (2) 1000 HP High Torque GE 752 Motors Each, 7,500 PSI Fluid Ends with P-Quip Liner and Piston Retention System.
TOP DRIVE
Canrig 1250AC 500 Ton Top Drive with 7,500 PSI Fluid System and Rig Floor Mounted TDSU
​
CATWALK
Canrig PC-3000 Hydraulic Catwalk with Walking Package, Hydraulic V-Door, Wireless Control
​
HANDLING TOOL
National ST-80C
​
​
ROTARY TABLE
National 275, 27.5′′ Table
​
​
BOP
13-5/8" 5,000 PSI Double Ram with 13-5/8" 5,000 PSI Annular
​
MUD SYSTEM
1,100 BBL with 6×8 Mixing Pumps and 10 HP Agitators, Desander, Desilter, 48” Mud/Gas Separator
SHALE SHAKER
(3) MI SWACO Linear Motion
​
​
CHOKE MANIFOLD
4” 5,000 PSI Skid Mounted
​
​
FUEL TANK
12,000 Gallon Dual Wall Fuel Tank w/ integrated redundant fuel pumps
​
WATER TANK
500 BBL
​
​
DOG HOUSE
10′ x 8′ x 45′ DS, 10’ x 8’ x 22’ ODS
​
​
TRAVELING BLOCK
National 500 Ton with 50” Sheaves for 1-3/8” Drilling Line
​
MISCELLANEOUS
Parts House, Pipe Racks, Misc. Handling Tools
​
LIGHTING SYSTEM
100% LED Class I DIV I, Class I DIV II Area, Spot and Flood Fixtures
​
POWER UNIT
Centralized HPU with Redundant Motors/Pumps and Temp/Level Protection
​
